Eco-Friendly Digital Treatment 2299-6 | Textile Printing Treatment | HY
HY 2299-6 is an eco-friendly digital treatment liquid specially formulated for textile printing. Features include vibrant ink colors, excellent wash fastness, no residue, soft hand feel, no odor, and won't clog digital printheads. Ideal for stretch cotton and various knitted fabrics.
Key Features:
Technical Specifications | 2299-6 Eco-Friendly Digital Treatment
Complete technical specifications for HY 2299-6 eco-friendly digital treatment liquid.
Product Specifications
Ready to Get Started?
For a free technical consultation, quote, samples, and custom specifications on Hybrid Printing Series, contact us—no obligation.
Eco-Friendly Certifications & Test Results
2299-6 meets strict international environmental and safety standards.
Certifications
GB 18401
Chinese textile safety standard
OEKO-TEX Standard 100
International textile safety standard
Adidas A-01
Adidas restricted substances list
Nike RSL
Nike restricted substances list
Eco-Friendly Test Results
| Parameter | Value | Standard |
|---|---|---|
| Soluble Heavy Metals | PASS | OEKO-TEX Standard 100 |
| AP (Aromatic Amines) | PASS | OEKO-TEX Standard 100 |
| APEO | PASS | Adidas A-01 |
| Phthalates | PASS | Nike RSL |
| Formaldehyde | <20 mg/kg | GB/T 7573-2009 |
| AZO Dyes | PASS | OEKO-TEX Standard 100 |
Performance Characteristics
Performance characteristics of 2299-6 eco-friendly digital treatment in textile printing applications.
Test Conditions
Fabric
100% Cotton (200x200mm solid print)
Printing Method
Print 1 pass, 3 strokes per pass
Curing Condition
140-150°C x 90s
Performance Metrics
Softness
4
4 (soft)
Internal standard: 5=very soft, 4=soft, 3=moderate, 2=slightly stiff, 1=stiff
Elasticity
2
2 (good)
Internal standard: 5=excellent, 4=good, 3=moderate, 2=fair, 1=poor
Wash Fastness
Pass
Tested at 40°C, 5g detergent, 1200rpm, 1.5h standard wash
Dry Rub Fastness
4
4
GB/T 3920-2008, 10 rub cycles
Wet Rub Fastness
4
4
GB/T 3920-2008, 10 rub cycles
Odor Test
None
GB 18401-2010, GB/T 14272-2011 - No detectable odor
Formulation & Auxiliaries
Recommended formulation and optional auxiliary agents for 2299-6 treatment liquid.
Auxiliary Agents
S627 Topcoat
Usage
1 coat after inkjet printing
Purpose
Topcoat for improved performance
Notes
For enhanced fastness and durability. Contains 1% PC-100.
Storage & Shelf Life
Proper storage conditions ensure optimal performance and extended shelf life of 2299-6 treatment liquid.
Storage Conditions
Temperature
5-35°C
Humidity
Keep in cool and ventilated place
Sealing
Well-sealed containers
Shelf Life
10 months from manufacturing date
Important Warnings
- ⚠Keep in cool and ventilated place
- ⚠Avoid direct sunlight and heat sources
- ⚠Store in well-sealed containers
- ⚠Do not freeze - storage temperature 5-35°C
- ⚠Perform compatibility test when using with non-HY auxiliaries
Application Guide | 2299-6 Eco-Friendly Digital Treatment
Detailed application instructions and technical parameters for optimal results with 2299-6 treatment liquid.
Printing Conditions
| Squeegee | 75° Oil-based |
| Screen Mesh | 100-200 mesh |
| Curing Condition | 140-150°C x 90s |
| Suitable Fabrics | Stretch cotton, knitted fabrics |
Printing Process
Print 2299-6 treatment liquid once on fabric
Flash dry thoroughly, then proceed with inkjet printing
After inkjet printing, flash dry until completely dry
Apply S627 topcoat once
Heat set at 140-150°C for 90 seconds
