Professional DTF White Ink for Epson i3200 | HY 1798-3
Optimized for high-volume production, HY 1798-3 provides superior whiteness and coverage. Engineered for Epson i3200 printheads, this dtf white ink maintains consistent flow during continuous operation.
Key Features:
Industrial DTF White Ink | HY 1798-3 Performance Solution
The HY 1798-3 dtf white ink is designed for professional apparel manufacturers seeking high-fidelity transfers. Specifically formulated for compatibility with Epson i3200 heads, it maintains stable jetting without clogging. Operators will appreciate the high opacity that makes colors pop on dark fabrics. Considering the needs of B2B production, this ink offers excellent wash fastness and stretchability. Typically, users find it ideal for high-speed dtf printer with white ink setups. Important: Proper ink management ensures long-term printhead health.
Chemical Properties & Technical Specifications | HY 1798-3
Comprehensive chemical metrics for HY 1798-3 professional dtf white ink. With a pH of 8.0-9.0 and viscosity under 5 mPa.s, professionals evaluating dtf ink for epson can ensure compatibility with high-speed industrial production. Our anion-charged formulation balances whiteness and particle suspension (180-220nm) for optimal jetting. Surface tension is maintained at 28-32 mN/m to ensure precise droplet formation.
Product Specifications
Need Help Choosing the Right Equipment?
Our professional team can provide personalized recommendations based on your business needs.
Contact UsEco-Friendly Certifications & Test Results
HY 1798-3 meets strict international environmental and safety requirements.
Certifications
OEKO-TEX 100
International textile safety standard
SGS Certified
Global quality and integrity standard
Harmful Substance Test Results
| Parameter | Value | Standard |
|---|---|---|
| Formaldehyde | < 10 ppm | OEKO-TEX 100 |
| Soluble Heavy Metals | PASS | Standard |
| APEO | PASS | OEKO-TEX 100 |
| Phthalates | PASS | OEKO-TEX 100 |
| AZO Dyes | PASS | OEKO-TEX 100 |
Finished Product Performance
Performance evaluation for HY 1798-3 white ink on standard cotton/polyester fabrics.
Test Conditions
Fabric
100% Cotton / Polyester Blends
Printing Method
Digital DTF Printing
Curing Condition
150°C * 90s
Performance Metrics
Softness
Grade 4
5-grade scale
Elasticity
Grade 5
5-grade scale
Gloss
Matte / Satin
Visual inspection
Machine Wash Fastness
Grade 4+
60°C wash cycles; consistent quality after multiple washes
Dry Rubbing Fastness
Grade 4
Standard test
Recommended Consumables & Auxiliaries
To achieve the best results with HY 1798-3 white ink, we recommend using high-quality compatible dtf supplies.
Auxiliary Agents
DTF Hot Melt Powder
Usage
Fine / Medium
Purpose
Adhesive layer for transfers
Notes
Ensures strong adhesion and soft hand-feel.
DTF PET Film
Usage
Cold / Hot Peel
Purpose
Transfer carrier
Notes
Double-sided matte coating for stable ink absorption.
Head Cleaning Solution
Usage
As needed
Purpose
Daily maintenance & cleaning
Notes
Use only approved solution for Epson heads.
Storage & Shelf Life
Storage instructions to maintain the chemical stability of HY 1798-3 white ink. Important: Extreme temperature fluctuations (outside 10-30°C) may lead to irreversible pigment sedimentation.
Storage Conditions
Temperature
10-30°C
Humidity
40-80% RH
Sealing
Keep container tightly sealed
Shelf Life
12 months from manufacturing date
Important Warnings
- ⚠Store in a cool and ventilated place (10-30°C) away from direct sunlight.
- ⚠Keep container tightly sealed when not in use.
- ⚠Avoid freezing and high-temperature environments.
- ⚠Gently shake or stir before each refill. Use within 1 month after opening.
Printing Guide | HY 1798-3 DTF White Ink
Operational parameters and printing process for HY 1798-3 professional white ink. Note: Operators should adjust curing times based on fabric weight and blend type.
Printing Conditions
| Humidity | 40-60% |
| Temperature | 18-28°C |
| Compatible Heads | Epson i3200 / 4720 |
| Media Type | DTF PET Film |
| Curing Temperature | 150°C |
| Curing Time | 90-120 seconds |
Printing Process
Gently shake the white ink container for 2-3 minutes to ensure uniform pigment distribution before refilling the dtf ciss system.
Fill the white ink tank and perform a nozzle check. Ensure the dtf printer with white ink maintains a stable temperature environment.
After printing, apply hot melt powder evenly and cure at 150°C for 90 seconds. For heavy cotton fabrics, extend curing to 110-120 seconds to ensure deep adhesion.
